| Matière du cadre |
High Performance Carbon |
|---|
| Batterie |
800Wh |
|---|
| Tailles |
Size Split |
|---|
| Réglage de l'angle de chasse |
0.6° |
|---|
| Équipement |
ABS |
|---|
| Collection |
Actionteam |
|---|
| cadre |
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing |
|---|
| taille |
Size Split: 27.5: S // 29: M, L, XL |
|---|
| moteur |
Bosch Drive Unit Performance Line CX max. 100Nm (BDU38) |
|---|
| Télécommande |
Bosch Mini Remote |
|---|
| batterie |
Bosch PowerTube 800 |
|---|
| écran |
Bosch Kiox 400C |
|---|
| chargeur |
Bosch 4A |
|---|
| Technologie ABS |
Bosch ABS Pro |
|---|
| fourche suspendue |
Fox 36 Float Factory GRIPX, Tapered, 15x110mm, E-Bike Optimized, 150mm (S: 140mm) |
|---|
| amortisseur |
Fox Float X Factory, 230x60mm (27.5: 210x55mm), Adjustable LSC/LSR w/ 2-Pos. Lever |
|---|
| entretoises d’amortisseur |
Front: 30x8mm, Rear: DU-Bushing 12.7mm |
|---|
| freins |
Shimano XT BR-M8220, Hydr. Disc Brake w/ Front ABS (203/203) |
|---|
| dérailleur arrière |
Shimano XT Di2 RD-M8260-SGS, 12-Speed, Electronic Shifting System |
|---|
| Commandes |
Shimano XT Di2 SW-M8250-IR, Direct Attach |
|---|
| Pédalier |
ACID MTB Hybrid Carbon, 27.5: 36T // 29: 34T |
|---|
| cassette |
Shimano XT CS-M8100, 10-51T |
|---|
| chaîne |
Shimano CN-M8100 |
|---|
| Guide-chaîne |
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
|---|
| jeu de direction |
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
|---|
| Potence |
CUBE Performance Stem E-MTB 35, FPI-Link |
|---|
| cintre |
Race Face ERA 35 |
|---|
| poignées |
ACID Disrupt |
|---|
| roues |
Newmen Beskar 30 base/strong, 28/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
|---|
| pneu avant |
Schwalbe Albert Trail Pro, Addix Soft, Kevlar, 2.5 |
|---|
| pneu arrière |
Schwalbe Albert Gravity Pro, Addix Soft, Kevlar, 2.5 |
|---|
| selle |
ACID Venec EMTB Trail 140 |
|---|
| tige de selle |
Fox Transfer Factory 31.6mm, Kashima Coated |
|---|
| pédales |
ACID PP MTB |
|---|
| couleur |
actionteam |
|---|
| poids |
24,2 kg |
|---|
| Poids maximum en charge |
160 kg |
|---|
