| Matière du cadre | High Performance Carbon |
|---|
| Batterie | 800Wh |
|---|
| Tailles | Size Split |
|---|
| Réglage de l'angle de chasse | 0.6° |
|---|
| cadre | C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing |
|---|
| taille | Size Split: 27.5: S // 29: M, L, XL |
|---|
| moteur | Bosch Drive Unit Performance Line CX max. 100Nm (BDU38) |
|---|
| Télécommande | Bosch Mini Remote |
|---|
| batterie | Bosch PowerTube 800 |
|---|
| écran | Bosch Kiox 400C |
|---|
| chargeur | Bosch 4A |
|---|
| fourche suspendue | Fox 36 Float Rhythm GRIP, Tapered, 15x110mm, E-Bike Optimized, 150mm |
|---|
| amortisseur | Fox Float Performance, 230x60mm (27.5: 210x55mm), Adjustable LSR w/ 2-Pos. Lever |
|---|
| entretoises d’amortisseur | Front: 30x8mm, Rear: DU-Bushing 12.7mm |
|---|
| freins | Shimano XT BR-M8220, Hydr. Disc Brake (203/203) |
|---|
| dérailleur arrière | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
|---|
| Commandes | Shimano XT SL-M8100-IR, 12-Speed |
|---|
| Pédalier | ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T |
|---|
| cassette | Shimano Deore CS-M6100, 10-51T |
|---|
| chaîne | KMC e12 |
|---|
| Guide-chaîne | Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
|---|
| jeu de direction | ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
|---|
| Potence | CUBE Performance Stem E-MTB 35, FPI-Link |
|---|
| cintre | CUBE Rise Trail Bar 35 |
|---|
| poignées | ACID Disrupt |
|---|
| roues | Newmen Performance 30 base/strong, 28/32 Spokes, 15x110mm / 12x148mm, Tubeless Ready |
|---|
| pneu avant | Conti Kryptotal Front, Enduro Soft, Tubeless Ready, 2.4 |
|---|
| pneu arrière | Conti Kryptotal Rear, Downhill Soft, Tubeless Ready, 2.4 |
|---|
| selle | ACID Venec EMTB Trail 140 |
|---|
| tige de selle | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
|---|
| pédales | ACID PP MTB |
|---|
| couleur | slabgrey´n´orange |
|---|
| poids | 24,3 kg |
|---|
| Poids maximum en charge | 160 kg |
|---|
| Poids maximal du cycliste | 125 kg |
|---|
