| Matière du cadre | Aluminium Superlite |
|---|
| Batterie | 600Wh |
|---|
| Tailles | Size Split |
|---|
| Équipement | FE |
|---|
| cadre | Aluminium Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost148, Fully Integrated Battery, Advanced Internal Cable Routing, 1.5 Headtube, Kickstand/Fender/Carrier Mounting Points |
|---|
| taille | Classic: Size Split: 27.5: S // 29: M, L, XL, XXL |
|---|
| moteur | Bosch Drive Unit Performance Line 75Nm (BDU34) |
|---|
| Télécommande | Bosch Purion 200 with Integrated Display |
|---|
| batterie | Bosch PowerTube 600 |
|---|
| chargeur | Bosch 2A |
|---|
| fourche suspendue | SR Suntour XCM34 NLO Coil, Tapered, 15x110mm, 120mm (27.5: 100mm) |
|---|
| freins | Shimano BR-MT200, Hydr. Disc Brake (180/180) |
|---|
| dérailleur arrière | Shimano Cues RD-U4000-GS, 9-Speed |
|---|
| Commandes | Shimano Cues SL-U4010- Rapidfire-Plus |
|---|
| Pédalier | ACID MTB Hybrid Pro, 38T |
|---|
| cassette | Shimano Cues CS-LG300, 11-46T |
|---|
| chaîne | KMC eGlide |
|---|
| Guide-chaîne | Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
|---|
| jeu de direction | ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface |
|---|
| Potence | CUBE Performance Stem E-MTB 35, FPI-Link |
|---|
| cintre | CUBE Rise Trail Bar 35 |
|---|
| poignées | ACID Hybrid Perform |
|---|
| roues | ACID Pro 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
|---|
| pneus | Schwalbe Smart Sam, Active, 2.6 |
|---|
| selle | ACID Sequence 160 |
|---|
| tige de selle | CUBE Performance Post, 31.6mm |
|---|
| pédales | ACID PP Trekking |
|---|
| éclairage avant | ACID Front Light PRO-E 150 X-Connect, 12V, DC |
|---|
| éclairage arrière | ACID Mudguard Rear Light PRO-E, 12V, DC |
|---|
| béquille | ACID FM Pure Kickstand |
|---|
| garde-boues | ACID 85 BB-Mount |
|---|
| sonnette | Knog Oi |
|---|
| Porte-bagages | ACID Carrier SIC 2.0 Rail Boost |
|---|
| couleur | indigoblue´n´reflex |
|---|
| poids | 26,5 kg |
|---|
| Poids maximum en charge | 150 kg |
|---|
| Poids maximal du cycliste | 120 kg |
|---|
