| Matière du cadre | Aluminium Superlite |
|---|
| Batterie | 600Wh |
|---|
| Tailles | Size Split |
|---|
| cadre | Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp |
|---|
| taille | Size Split: 27.5: S // 29: M, L, XL |
|---|
| moteur | Bosch Drive Unit Performance Line CX max. 100Nm (BDU38) |
|---|
| Télécommande | Bosch Purion 200 with Integrated Display |
|---|
| batterie | Bosch PowerTube 600 |
|---|
| chargeur | Bosch 2A |
|---|
| fourche suspendue | SR Suntour XCR34X 2CR Air, Tapered, 15x110mm, 120mm |
|---|
| amortisseur | SR Suntour EdgeX R 185x52.5mm, Rebound Adjust, Trunnion Mount |
|---|
| entretoises d’amortisseur | Top: 54mm Trunnion Mount, Bottom: 22.2x8mm |
|---|
| freins | Shimano BR-MT420, Hydr. Disc Brake (203/203) |
|---|
| dérailleur arrière | Shimano Cues RD-U6000-GS, 10-Speed |
|---|
| Commandes | Shimano Cues SL-U6000, Rapidfire-Plus |
|---|
| Pédalier | ACID MTB Hybrid Pro, 38T |
|---|
| cassette | Shimano Cues CS-LG300, 11-48T |
|---|
| chaîne | KMC eGlide |
|---|
| Guide-chaîne | Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
|---|
| jeu de direction | ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface |
|---|
| Potence | CUBE Performance Stem E-MTB 35, FPI-Link |
|---|
| cintre | CUBE Rise Trail Bar 35 |
|---|
| poignées | ACID Hybrid Perform |
|---|
| roues | ACID PRO 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready |
|---|
| pneus | Schwalbe Smart Sam, Active, 2.6 |
|---|
| selle | ACID Venec EMTB Plus 145 |
|---|
| tige de selle | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
|---|
| pédales | ACID PP MTB |
|---|
| couleur | night´n´chrome |
|---|
| poids | 25,8 kg |
|---|
| Poids maximum en charge | 150 kg |
|---|
| Poids maximal du cycliste | 120 kg |
|---|
