| Matière du cadre | Aluminium Superlite |
|---|
| Batterie | 600 Wh |
|---|
| Tailles | Size Split |
|---|
| cadre | Aluminum Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp |
|---|
| taille | Classic: Size Split: 27.5: S // 29: M L XL XXL |
|---|
| moteur | Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System |
|---|
| Télécommande | Bosch Purion 200 w/ Integrated Display |
|---|
| batterie | Bosch PowerTube 600 |
|---|
| chargeur | Bosch 2A |
|---|
| fourche suspendue | SR Suntour X1-32 LO-R Air, Tapered, 15x110mm, 120mm (27,5: 100mm) |
|---|
| freins | Shimano BR-MT200, Hydr. Disc Brake (180) |
|---|
| dérailleur arrière | Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
|---|
| Commandes | Shimano Deore SL-M6100-R, Rapidfire Plus |
|---|
| Pédalier | ACID MTB Hybrid Pro, 38T |
|---|
| cassette | Shimano Deore CS-M6100, 10-51T |
|---|
| Guide-chaîne | Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
|---|
| jeu de direction | ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) |
|---|
| Potence | CUBE Performance Stem E-MTB 35, FPI-Link |
|---|
| cintre | CUBE Rise Trail Bar 35 |
|---|
| poignées | ACID React Pro |
|---|
| jantes | CUBE EX30, 32H, Disc, Tubeless Ready |
|---|
| moyeu avant | CUBE Engineered By Newmen, 15mm, Boost, Centerlock |
|---|
| moyeu arrière | CUBE Engineered By Newmen, 12mm, Boost, Centerlock |
|---|
| pneus | Schwalbe Smart Sam, Active, 2.6 |
|---|
| selle | ACID Sequence Pro 160 |
|---|
| tige de selle | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
|---|
| pédales | ACID PP MTB |
|---|
| couleur | metallicgrey´n´black |
|---|
| poids | 24,3 kg |
|---|
| Poids maximum en charge | 140 kg |
|---|
| Poids maximal du cycliste | 110 kg |
|---|
